Nylon Canvas Framework (Common Model on the Market): Excellent flexibility, resistant to cracking even after repeated bending, suitable for daily lifting and semi-dam operation; however, it has a low tensile strength limit. When the dam height exceeds 5m, multiple layers are required, causing a significant increase in the weight of the dam bag, making it prone to tensile deformation under high water pressure.
Carbon Steel Wire Framework: High tensile strength, suitable for 8-10m ultra-high dams; its fatal flaws include seepage, corrosion, expansion, and cracking of the rubber; high rigidity leading to severe bending fatigue; it is basically unusable in northern regions due to frost heave and coastal chloride ion environments; repair requires complete section cutting and replacement.
According to the SL227 standard, the new framework must simultaneously consider four key indicators: tensile strength, bending flexibility, corrosion resistance, and ease of repair, addressing the shortcomings of both traditional materials.
Advantages:
Maximum Strength and Lightweight: Tensile strength is 3-5 times that of nylon and 5 times that of ordinary steel wire, while the weight is only 1/5 that of steel wire; for the same tensile strength, the number of aramid layers is halved, resulting in a 30% reduction in overall dam bag weight, a 20% increase in the inflatable dam's lifting speed, and a significant reduction in energy consumption of the inflation and deflation system.
Flexible and Resistant to Bending and Compressive Force: Retains fiber flexibility, preventing rigid stress cracking during repeated dam collapses and low-level operation of the dam, perfectly avoiding the bending defects of steel wire skeletons; resistant to UV radiation and acid/alkali corrosion, with excellent adaptability to coastal saline tides and sewage rivers.
Construction and Maintenance Friendly: Excellent adhesion to rubber vulcanization; localized damage can still be repaired with cold bonding, eliminating the need for complete replacement; uniform coloring of colored landscape dams prevents color difference and fading issues. Applications: Urban landscape rubber dams, 5-8m medium-high head dams, coastal waterways, and projects requiring regular semi-dam operation; replacing nylon skeletons in the renovation of old dams, increasing overall lifespan from 8-12 years to 20-25 years.
Disadvantages: High raw material unit price; cost-effectiveness is improving year by year after domestic aramid mass production reduces costs.
Characteristics: Optimal impact resistance and silt penetration resistance; abrasion resistance far exceeds aramid and nylon; acid and alkali resistant, low-temperature resistant; mechanical properties do not decrease in cold environments down to -40℃; significant advantages specifically for northern waterways.
Disadvantages: Weak high-temperature resistance; modulus slightly decreases in areas exposed to strong sunlight in summer; high threshold for vulcanization process; mostly used as a single-layer reinforced skeleton in river sections with severe sand and gravel erosion, such as main streams with high silt content and tributaries of the Yellow River.
Advantages: Carbon fiber has extremely high modulus and minimal deformation, resulting in almost no tensile deformation of the dam body under high water pressure; it is chemically inert and completely rust-free, compensating for the corrosion shortcomings of steel wire.
Limitations: It is relatively brittle, easily breaking fibers upon impact with a single hard object; it is not typically used as a standalone dam skeleton. It is generally mixed with aramid fibers and used as a reinforcement layer in the anchorage area at the bottom of high dams. It is only used for local reinforcement of ultra-high dams over 6 meters in height, and its cost-effectiveness is low for full-area application.
This composite structure was developed to address the issues of pure steel wire's rust susceptibility and pure aramid's high cost. The main reinforcing bars use steel wire to withstand high tensile forces, while the outer layer of aramid fiber provides water insulation and rust prevention, balancing strength and flexibility.
Applications: High dams for irrigation in remote farmland; unattended field water conservancy projects; not recommended for urban landscape waterways, as poor bonding process control of the interlaced layers can lead to delamination.
1. Nano-Modified EPDM Composite Vulcanization Process: Graphene and nano-ceramic powder are added to the rubber layer of the dam bag, and it is vulcanized integrally with a new aramid reinforcement, increasing bonding strength by 40% and reducing the likelihood of delamination under water flow vibration. A polyurea spray coating provides surface protection, offering dual protection against erosion and aging.
2. Continuous Wide-Width Vulcanization Production: The new long-fiber reinforcement can be woven and vulcanized in its entirety, reducing dam body splicing seams, lowering the probability of anchorage leakage, and conforming to the SL227 anchorage construction standard.
1. Urban landscape rivers and frequently raised/lowered dams: Aramid canvas skeleton is preferred; it offers high flexibility, good aesthetic appeal, and compliant semi-dam operation.
2. Rivers with high sediment content, such as the Yellow River: UHMWPE fiber skeleton, wear-resistant and resistant to sand and gravel impact.
3. Coastal seawater and acid/alkali sewage rivers: All-aramid, resistant to chloride ion corrosion, eliminating the risk of rust.
4. Irrigation dams in cold northern regions: UHMWPE/modified nylon, resistant to low-temperature frost heave.
5. Ultra-high head dams (over 8m in height): Aramid + carbon fiber local reinforcement; pure carbon steel wire is prohibited.
1. Short-term (within 3 years): Aramid skeletons will gradually replace nylon as the mainstream material for urban landscape dams. Mass production of domestically made aramid fibers will reduce costs, leading to a rapid increase in market penetration.
2. Medium- to long-term trends: High-performance all-fiber skeletons will completely replace carbon steel wire. Composite modified skeletons combined with intelligent monitoring will be implemented, with stress-sensing lines embedded inside the skeleton to monitor tensile deformation in real time and provide early warnings of dam bag damage.
3. Regulatory guidance: The revision of SL227 encourages flexible high-strength fiber skeletons and strictly controls the use of carbon steel wire across all areas, reducing the risk of corrosion and flooding from the design stage.
